Technical Data

Model		GZP-26 ZPT-26	GZP-32 ZPT-32		GZP-40 ZPT-40
No. of stations		26	32		40
Tooling type		D	B		BB
Output range	Tablets/h	34000~171000	42000~211000		52000~264000
Rotation speed range	rpm	22~110
Main pressure	KN	100
Pre-pressure	KN	16
Max tablet diameter	mm	Ø25	Ø16		Ø13
Max length of irregular tablet	mm	25	19		16
Diameter of die	mm	Ø38.1	Ø30.16		Ø24
Max. filling depth	mm	20	20		16
Diameter of punch	mm	25.35		19
Length of punch	mm	133.6
Pitch circle diameter	mm	370
Main motor power	kW	7.5
Weight	kg	1450
Dimensions (LWH	mm	82011001750
